The new TranzX F15 front wheel mount motor provides the assistance to get you to where you want to go quickly and smoothly
The latest generation 400Wh battery provides a range of 30 – 50 miles depending on the terrain your riding on
The comfortable upright riding position makes it a pleasure to ride this bike
Fully equipped with rack, mudguards and a kick stand so that you're ready to go straight from the shop
CST Zeppelin high volume tyres with puncture protection and reflective stripe make your ride comfortable and safer
8 wide range Shimano gears to help you get up the hills
The Selle Royal Saddle is comfortable and has protective scuff guards to help prevent damage
Components
Stem: Raleigh Alloy adjustable quill stem
Handlebars: Raleigh Comfort Handlebar Silver
Grips: Velo comfort grips
Saddle: Velo men's comfort saddle
Seatpost: Alloy micro adjust
Seat clamp: 31.8 Clamp
Electrical
Motor: New TranzX F15 36v 250w brushless Quick stop motor
Battery: TranzX 400wh 36V 11Ah Battery
Display: TranzX DP15 PST Display, 3 assist levels with Walk Function
Sensor: TranzX Speed Sensor
Range: Eco 50-65 miles
Frameset
Frame: Aluminium 6061
Rear derailleur dropout: Alloy Replaceable Hanger
Fork: Raleigh Steel trekking fork for E bike
Headset: Threaded 1" 1/8th silver
Groupset
Shift levers: Shimano Revoshift 8 Speed
Brake levers: Alloy V-brake with cut off quick stop function.
Rear derailleur: Altus 8 Speed
Front brake: V-Brake
Rear brake: V-Brake
Crankset: Alloy forged 170mm, 42t
Bottom bracket: 124.5 MM Square taper
Freewheel/cassette: 8 SPEED 11-32 cassette
Chain: KMC 8 Speed Chain
Pedals: Comfort Pedals with Anti Slip
Wheelset
Front wheel: Double Wall rim 36 hole 700c on TranzX F15 Motor hub
Rear wheel: Double Wall rim 36 hole 700c on Cassette hub
Front hub: TranzX Motor hub
Rear hub: Alloy 8 speed cassette Hub 36 hole
Rims: Double Wall rim 36 hole 700c
Front tyre: CST Zeppelin 700 x 40c with tan side wall
Rear tyre: CST Zeppelin 700 x 40c with tan side wall
Inner tubes: 700x38c presta
| Battery Size |
11 Ah / 400 Wh
|
| Wheel Size |
700c
|
| Range (miles) |
40-60
|
| Top Speed (mph) |
15.5
|
| Brand |
Raleigh
|
TranzX 400wh 36V 11Ah Battery
